Features
- up to 12V 80A contact load
- 1 Form A & 1 Form C contact arrangement
- 9.5 mm & 6.3 mm Terminals
- Ambient temp. range up to 125℃
- RoHS & ELV compliant available
English
English
Features
|
Contact Ratings |
|
|
Contact Form |
1A, 1B, 1C |
|
Contact Load Volt. |
13.5VDC/27VDC |
|
Contact Material |
AgSnO2 |
|
Electric Endurance |
1*105 |
|
Mechanical Endurance |
1*106 |
|
Coil Ratings |
|
|
Nominal Volt. |
12V/24V |
|
Pick-up Volt. |
≤8VDC/16VDC |
|
Release Volt. |
≥1.2VDC/2.4VDC |
|
Coil Res. |
80Ω/320Ω |
|
Coil Power |
1.8W |
|
Max. Coil Volt. (23℃) |
20.2VDC/40.5VDC |
|
Max. Coil Volt. (85℃) |
15.7VDC/31.5VDC |
